Overview

Hubbell Twist-Lock® Family | Watertight Safety-Shroud Series — 30 Amp, 3Φ 480 and 3Φ 600 Volts AC 3 Pole, 4 Wire, Grounding:

Washdown environments can be challenging to clean. Not only do electrical products need to withstand high-pressure washdowns and harsh chemicals, but complete runoff is also important. Whether it's Watertight devices, Watertight Safety-Shroud® Twist-Lock® devices or IEC Pin & Sleeve devices, Hubbell’s extensive offering of devices meet the challenge . Hubbell manufactures an extensive line of back boxes for use with IEC Pin and Sleeve devices. Each back box is designed to give the user the maximum amount of wiring room while achieving grounding to metallic conduit. Hubbell back boxes are available in non-metallic and cast metal versions.

Food processing areas can be particularly corrosive for electrical connections, calling for an extra level of safety and protection. Hubbell offers a wide range of plugs, connectors, and receptacles that are specifically designed to withstand corrosive environments. Extreme temperature changes can wreak havoc on electrical components and devices that aren’t constructed to withstand a food processing environment. Hubbell products are designed to withstand temperature fluctuations and accommodate expansion and contraction when necessary.

Shrouded Watertight Construction Features:

UL Type 4X Environmental seal protects connection while in use

One-piece, engineered thermoplastic housing is impact-resistant for heavy-duty industrial environments

Alignment arrows and lock and unlock symbols provide a visual indication that devices are properly connected

Closure cap is included for environmental seal when device is not in use

Catalog number and color-coded voltage rating are easily visible even when in use

Watertight Safety-Shroud® Twist-Lock® System Features:

Constructed of highly impact-resistant PBT thermoplastic for a UL Type 4X rating in heavy duty environments

Safety-Shroud virtually eliminates bent and broken plug blades, leading to longer equipment life while providing extra protection for personnel

Virtually eliminates bent and broken plug blades, leading to longer equipment life

Extends life of mating receptacles by eliminating damage caused by insertion of bent blades

Extra protection for personnel by significantly reducing chance of inadvertent contact with blades when connecting or disconnecting energized receptacles and connector bodies

Reduces exposure to arcing when connecting or disconnecting plugs under load

Compliance with California Code of Regulations, Title 8, Article 51, subsection 2510.7(b), which requires shrouding for devices exceeding 300 volts

Lockout/tagout hole allows compliance with OSHA regulation 29 CFR 1910.147

IEC Watertight and Switch-Rated Pin & Sleeve Devices Features:

The UV-stabilized, impact and corrosion-resistant PBT housing is designed to withstand harsh industrial environments

Advantage™ Series Switch-Rated Pin & Sleeve has superior water ingress protection, UL
witnessed IP69k and UL Type 4X and 12. Device is built to withstand wet and harsh environments

The sleek and modern design of the ergonomic device is easy to keep clean making it ideal for hygienic food processing facilities
